• Conforms to DIN 41494 or Equivalent EIA / ISO / EN Standard
• Open architecture for easy access to cable and unrestricted air flow
• Adjustable depth 650 to 850 mm to suite site conditions
• High-strength, lightweight 6061-T6 aluminum extrusion constructions
• Two top angles and heavy-duty assembly hardware for a stronger rack to handle heavier loading
• 25 No. M6 mounting screws with combination Phillips/ straight heads and pilot points to reduce cross threading and installation time
• Unique packaging inserts eliminate damage from components hitting together in the carton during shipping and handling.
• Ease of assembling by high quality fasteners.
• Universal 12.7mm-15.875mm-15.875mm alternating hole pattern offers greater mounting flexibility, maximizes usable mounting space
• Numbered U positions
• Panel Mounting Holes: M6 threads in both flanges
• Powder Coated or anodized provide a uniform appearance and protection against aluminum oxidation corrosion
• State-of-the-art manufacturing methods provide the best product quality and fastest delivery in the industry
• Conductive M6 tapped DIN standard holes -100% assured conductivity within the rack. Eliminate separate grounding strip.
• Heavy duty bottom (160X60X8Th) MM & top angles (38X38X4.8Th) MM and C frames (32X75X5Th) MM to ensure up to 1500Kg static load capacity
• Custom configurations and assemblies available by special order
• Assembly hardware is included
• Weight capacity of 1500Kg Static (weight must be evenly distributed)


Note:

• Overall Height = Frame Height+Plinth or Caster. Other models can be manufactured on request
• It is recommended to distribute the Load along with U space in the Rack

Abbreviations:

H - Overall height
h - Usable height
W - Overall width
w - Usable width
