OVERVIEW
Managing more servers at rack level with single monitor and key board OR LCD Console drawer is a challenge and as entry level we need some devise to manages this cost effectively. NetRack understand the requirement introduce Analogue 8 and 16 port KVM which can be cascadable till 8 levels. Interestingly Analogue KVM are used in all SOHO, SMB and Enterprise segment.
Technical Specification
KVM Specification
| KVM Port | |
|---|---|
| Number of ports: | 8 or 16 |
| Connector: | DB-15 combo connector |
| Connectivity: | Combo 4-in-1 KVM cable, up to 6, 10 & 15 feet |
| Local Console | |
|---|---|
| Graphic Connector: | 1 x DB-15 VGA |
| Resolution: | Up to 1920 x 1080 / 1920 x 1200 |
| Input Device: | 2 x USB type A for keyboard & mouse |
| Management | |
|---|---|
| Multilingual OSD: | English, France, German, Spanish,Italian, Russian, Simplified Chinese,Japanese |
| Hotkey Combination: | Scroll-lock, Cap-lock, Num-lock,Alt, Ctrl & Win |
| Security: | Password enable & disable, up to 8 users profile for access |
| PC Selection: | Front button, OSD menu & hotkey |
| Expansion | |
|---|---|
| Up to 128 servers by 8-level cascade |
| Compatibility | |
|---|---|
| Multi-Platform: | Mix PCs, SUN and Mac G3 |
| G4 Mac / iMac Support: | Windows 7 / Vista / 2003 XP, Linux, Unix |
| Power | |
|---|---|
| Input: | Auto sensing 100 to 240VAC, 50/60 Hz |
| Option DC: | 12V/24V/48V/110 ~ 125V DC input |
| Consumption: | Max. 24 Watt, Standby 5 Watt |
| Regulatory | |
|---|---|
| Safety: | cUL, FCC & CE certified |
| Environment: | RoHS2 & REACH compliant |
| Environmental | |
|---|---|
| Operating: | 0 to 55°C |
| Storage: | -5 to 60°C |
| Relative Humidity: | 90%, non-condensing |
| Shock: | 50G peak acceleration(11ms, half-sine wave) |
| Vibration: | 58~100Hz / 0.98G (11ms / cycle) |
| Product Information | |
|---|---|
| Dimension (W x D x H): | 443 x 171 x 44 mm/17.4 x 6.7 x 1.73 inch |
| Net Weight: | 2.4 kg / 5.3 lb ( CV-S801 ) 2.6 kg / 5.7 lb ( CV-S1601 ) |
| Packing Information | |
|---|---|
| Dimension (W x D x H): | 500 x 400 x 90 mm / 19.7 x 15.7 x 3.5 inch |
| Gross Weight: | 3.9 kg / 8.6 lb ( CV-S801 ) 4.2 kg / 9.2 lb ( CV-S1601 ) |
Features & Accessories
Combo DB-15 KVM Benefits
- Combo DB-15 KVM with either 8 or 16 ports in 1U
- Cascade switches up to 8 levels & Mix switches between Cat6 & Combo DB-15 KVM
- Mix PS/2, USB & SUN with Multi-Platform switch capability
- Support resolution up to 1920 x 1080
- SUN 1152 x 900 resolution compatible
- Hot pluggable, no software or drivers required
- Easy & quick installation
Switch Features & Options
- Multi lingual on screen display menu
- Advanced user profiles and configurable OSD hot key combinations
- DC power options : 12V / 24V / 48V / 110 ~ 125V
Ordering Information
| Console | Local | Remote | IP | 8-port | 16-port |
|---|---|---|---|---|---|
| 1 | 0 | 0 | NR-CV-S801 | NR-CV-S1601 |
